제품 라인업

제품 라인업

자동화 실현은 현재 제조업체가 추구하는 추세입니다. Dobot은 현재 사회 요구에 순응하여 빠른 배치, 안전한 협동작업을 실현함과 동시에 신뢰성과  유연성을 갖춘 효율적인 협동로봇을 연구해 왔습니다. 당사 로봇은 고객의 다양한 요구를 만족할뿐만 아니라 더욱 경쟁력 있는 가격을 갖추어 최대 효율 솔루션을 제공해드릴수 있습니다.

Please fill in the information below for further product information.

세이프 스킨
혁신적인 사전 충돌 감지 기술

더 안전한 위한 Dobot 독점 기술
더 알아보기
zzz
zzz

제품 사양



모델 CR3 CR5 CR7 CR10 CR12 CR16 MG400 M1 Pro
축 수 6 6 6 6 6 6 4 4
무게 16.5 kg 25 kg 24.5 kg 40 kg 39.5 kg 40 kg 8 kg 15.7 kg
최대 부하 하중 3 kg 5 kg 7 kg 10 kg 12 kg 16 kg 0.75 kg 1.5 kg
작업 반경 620 mm 900 mm 800 mm 1300 mm 1200 mm 1000 mm 440 mm 400 mm
반복 정밀도 ±0.02 mm ±0.02 mm ±0.02 mm ±0.03 mm ±0.03 mm ±0.03 mm ±0.05 mm ±0.02 mm
정격 전압 48V DC

DOBOT을 선택할 이유

Dobot은 스마트 협동로봇 글로벌 선도 기업이자 데스크탑 레벨 로봇 암의 창시자이기도 합니다. 중국과학원, 청화대, 할빈공업대학, 산동대학, MIT 및 기타 명문 대학과 연구소 출신 인재로 구성된 DOBOT의 핵심성원들은 AI, 시스템 통합, 지능형 감지 등의 핵심 기술을 자체적으로 부단히 연구 개발하여 왔습니다.
Dobot 은 고객이 최소의 투자로 최대의 효과를 달성할 수 있도록 제조, 헬스케어, 서비스 및 소매 부문, 자동화 구현, 지능화 전환 및 유연 생산의 솔루션을 제공하고 있습니다. Dobot은 산학융합을 통해 업계에서의 경험과 학계의 교육과 융합하여 산업업계를 발전시킬 차세대 인재를 육성에 주의를 돌리고 있습니다.
  • 100 +

    국가 및 지역

  • 68000 +

    판매량

  • #1

    해외 로봇 수출량

  • 350 +

    파트너

  • 1200 +

    지적재산권

  • 40 %

    연구 개발 인력

글로벌 파트너

산업 혁신에 중시를 돌려 더 아름다운 미래를 위해 지속적으로 노력할것을 약속합니다.
  • 1
  • 2
  • 3
  • 4
  • 5
  • 6
  • 7
  • 8
  • 9
  • 10
  • 11
  • 12
  • 13
  • 14
  • 15
  • 16
  • 17
  • 18
  • 19
  • 20
  • 21
  • 22
  • 23
  • 24

Dobot 대리점 가입하기

지금 지원

CR Collaborative Robot Series

Model CR3 CR5 CR7 CR10 CR12 CR16
Weight 16.5 kg 25 kg 24.5 kg 40 kg 39.5 kg 40 kg
Maximum Payload 3 kg 5 kg 7 kg 10 kg 12 kg 16 kg
Working Radius 620 mm 900 mm 800 mm 1300 mm 1200 mm 1000 mm
Max Reach 795 mm 1096 mm 990 mm 1525 mm 1425 mm 1223 mm
Rated Voltage DC48V
Maximum Speed of TCP 2 m/s 3 m/s 3 m/s 4 m/s 4 m/s 3 m/s
Joint Ranges J1 ±360°
J2 ±360°
J3 ±155° ±160° ±160° ±160° ±160° ±160°
J4 ±360°
J5 ±360°
J6 ±360°
Maximum Speed of Joints J1/J2 180°/s 180°/s 180° /s 120°/s 120° /s 120°/s
J3/J4/J5/J6 180°/s
End-Effector I/O Interface DI/DO/AI 2
AO 0
Communication Interface Communication RS485
Controller I/O DI 16
DO/DI 16
AI/AO 2
ABZ Incremental Encoder 1
Repeatability ±0.02 mm ±0.02 mm ±0.02 mm ±0.03 mm ±0.03 mm ±0.03 mm
Communication TCP/IP, Modbus, Wi-Fi
IP Rating IP54
Temperature 0℃~ 45℃
Power 120W 150W 150W 350W 350W 350W
Materials Aluminum alloy, ABS plastic

* The above data is the test results obtained by Dobot Laboratory under controlled experimental conditions, which may have slight differences from those in actual application scenarios.
